• Resource estimates and sampled kernel outcomes describe different programs. Neither demonstrates quantum advantage; this is not a quantum-state animation.
• No successful local-simulator histogram in the selected run source.
• Archived problem; not an active quantum-advantage candidate.
• This poster was rendered from an earlier estimate (18 logical, 80,322 physical qubits for Main.HHLSolve2x2([[4.0, -1.0], [-1.0, 3.0]], [15.0, 10.0], 3)). The kernel or the estimated program changed on 2026-09-26; the current estimate is 23 logical, 86,567 physical qubits for Main.HHLSolve2x2([[4.0, -1.0], [-1.0, 3.0]], [15.0, 10.0], 3).

This run was recorded in April 2026 against a kernel that was not HHL, replaced by textbook HHL on 2026-09-26. The shot distribution below is a real measurement, but it is a measurement of a program that no longer exists in this repository, and it has not been re-run against the current kernel.

HHL offers exponential speedup but with critical caveats: (1) requires efficient state preparation, (2) only provides quantum state output (readout bottleneck), (3) condition number κ must be polylog(N). Practical utility requires all three conditions simultaneously.

04. Quantum Linear Solvers

This archived challenge now contains a checked textbook HHL circuit for the 2x2 symmetric system

A = [[4, -1], [-1, 3]]
b = [15, 10]

The classical solution is x = [5, 5], so the normalized solution distribution is [0.5, 0.5]. The Q# circuit keeps the existing Main.HHLSolve2x2([[4.0, -1.0], [-1.0, 3.0]], [15.0, 10.0], bits) entry shape. It returns one system-qubit sample after post-selecting the ancilla on One. Main.HHLJointSample2x2 and HHLKernel() return [ancilla, system] so callers can post-select directly.

Correction (2026-09-26)

Earlier text and code said this problem implemented HHL. It did not. The old Hamiltonian simulation used first-order Rz and Rx steps instead of exact controlled exp(i A t 2^k), the inversion used per-bit angles instead of 2 asin(C/lambda), and the hardware kernel returned only the ancilla. For this matrix the old circuit produced about P(system = 1) = 0.309, while the true normalized A^-1 b distribution is [0.5, 0.5]. The replacement implements exact controlled evolution for real 2x2 Hermitian matrices, big-endian QPE, clock-value controlled inversion with C = 1, inverse QPE, and explicit ancilla/system measurement.

Verified numbers

For the 3-bit clock used by tooling/estimator_config.py and HHLKernel():

| Quantity | Value |

|---|---:|

| Ancilla success probability | 0.2034890696 |

| Post-selected system distribution | [0.47915502, 0.52084498] |

| Fidelity with normalized classical solution [0.5, 0.5] | 0.9995652979 |

| Joint [ancilla, system] distribution | (0,0): 0.5708907296; (0,1): 0.2256202008; (1,0): 0.0975028096; (1,1): 0.1059862600 |

For the 4-bit calibration entry in tooling/generate_calibration_ensemble.py:

| Quantity | Value |

|---|---:|

| Ancilla success probability | 0.1507474826 |

| Post-selected system distribution | [0.50403167, 0.49596833] |

| Fidelity with normalized classical solution [0.5, 0.5] | 0.9999837453 |

The fidelity is below one because the eigenvalues (7 +/- sqrt(5)) / 2 fall between clock values. Each controlled-evolution step is exp(i A 2 pi/8) whatever the clock size, so every added clock bit halves the eigenvalue resolution and the output converges on the solution (fidelity 0.99957, 0.99998 and 0.99999 with 3, 4 and 5 bits). A step that shrank as 2 pi / 2^m would fix the resolution at 1, and extra bits would then move the output slightly away from the solution.

How to run

cd problems\archived\04_linear_solvers
make classical
make analyze
make run

A direct QDK smoke test is:

$env:PYTHONIOENCODING='utf-8'
python -c "from qdk import qsharp; qsharp.init(project_root='problems/archived/04_linear_solvers/qsharp'); print(qsharp.run('Main.HHLSolve2x2([[4.0, -1.0], [-1.0, 3.0]], [15.0, 10.0], 3)', shots=10))"

Files

• `qsharp/src/Main.qs`: Q# implementation and demo entry point.
• `qsharp/HardwareKernel.qs`: standalone Azure-style kernel returning `[ancilla, system]`.
• `python/classical_baseline.py`: dense classical baseline for the YAML instances.
• `python/analyze.py`: plots condition numbers and residuals.
• `instances/small.yaml`, `instances/medium.yaml`, `instances/large.yaml`: problem instances for the classical baseline.
• `estimates/latest_*.json`: mock estimator artifacts from the previous pipeline. They are superseded for algorithm correctness and must not be read as estimates of the corrected HHL circuit.

Scope and caveats

This is a 2x2 pedagogical HHL instance, not evidence of practical advantage. HHL's exponential speedup requires efficient state preparation, sparse well-conditioned matrices, and a task that needs expectation values of |x> rather than a full classical readout. See Harrow, Hassidim and Lloyd, arXiv:0811.3171; Aaronson, Nature Physics 11, 291 (2015); and Tang, arXiv:1807.04271 for the data access and dequantization caveats.

Objective maturity gate

• Current gate: Stage B with a checked toy HHL circuit and classical baseline.
• Next gate target: Stage C, which needs calibration and noise evidence for the corrected circuit; its resource estimate was regenerated on 2026-09-26.

Stage C exit criteria remain:

• Execute a non-placeholder quantum workflow tied to the problem objective.
• Report uncertainty-bounded comparisons between classical and quantum outputs on `small` and `medium` instances.
• Document transpilation, connectivity and backend assumptions for reported quantum runs.
• Add calibration and noise-sensitivity evidence for reported quantum metrics.

DiVincenzo Readiness (Stage C/D Overlay)

| Criterion | Status | Evidence / Notes |

|---|---|---|

| Scalable qubit system | partial | The 2x2 instance is estimated at 86,567 physical qubits and 23 logical qubits (circuits/estimate.json); larger systems are not implemented. |

| Initialization | partial | The right-hand side is loaded with one Ry rotation; loading an N-dimensional classical vector costs O(N) gates in general. |

| Coherence vs gate time | not-yet | No backend-calibrated coherence evidence exists for the corrected circuit. |

| Universal gate set | met | Exact controlled exp(iAt), phase estimation, the controlled Ry inversion and inverse phase estimation are implemented and checked against exact simulation (tooling/test_hhl_kernel.py). |

| Qubit-specific measurement | partial | The hardware kernel returns the ancilla and the system qubit so shots can be post-selected; hardware readout characterization is pending. |

Advantage Claim Contract

• **Claim category (current)**: `theoretical`.
• **Problem class and regime**: A 2x2 symmetric positive-definite system solved by textbook HHL with a 3-bit clock (4-bit in calibration).
• **Fair baseline**: The direct solution in `python/`, exact and instantaneous at this size; conjugate gradient is the scalable classical comparator for sparse systems.
• **Quantum resource scaling claim**: HHL runs in time polylogarithmic in N for sparse, well-conditioned A, given efficient state preparation and when only expectation values of x are needed (Harrow, Hassidim and Lloyd, arXiv:0811.3171). None of these conditions is demonstrated here.
• **Data-loading and I/O assumptions**: Loading b and reading out x each cost O(N) for classical data (Aaronson, Nature Physics 11, 291, 2015), which removes the advantage for generic classical inputs; low-rank inputs are dequantized (Tang, arXiv:1807.04271).
• **Noise/error model assumptions**: Noiseless simulation; the resource estimate assumes a surface code at a 10^-3 physical error rate.
• **Confidence/uncertainty method**: State-vector comparison with an independent model of the circuit to 1e-9, and sampled outputs within five standard errors or a total-variation tolerance.
• **Residual risks**: State preparation, readout and the condition number dominate at any useful size.
